 Handheld Two-way Radio with Dual band Dual frequency Dual display Dual standby KG-UVD1P









Functions ( KG-UVD1P):

•  CE FCC approved.(FCC ID:WVTWOUXUN04)

• Frequency Range Can Be Suitable For Different Countries or Areas
136-174&350-470 MHz (RX/TX)
136-174&400-480 MHz (RX/TX)
136-174&420-520 MHz (RX/TX)
136-174&400-470 MHz (RX/TX)
136-174&245-250 MHz (RX/TX)
136-174&216-280 MHz (RX/TX)
136-174&225-226 MHz (RX/TX)
144-146&430-440 MHz (RX/TX)
FM: 76-108 MHz(RX)
• Work Mode:U-V、U-V、V-V、U-U can be set freely
• SOS Function
• 1750Hz tone
• DTMF Encoding Function
• CTCSS/DCS Scan(Digital/Analog)
• Bright Flashlight Illumination
• Band Can Be Set Freely on The Same Channel VHF TX-UHF RX or UHF TX-VHF RX
• English Voice Guide
• Digital FM Radio
• Wide/Narrow Bandwidth Selection(25khz/12.5khz)
• Priority Scan, Add Scanning Channel
• High/Low Power Selection
• Channel Name Edit and Display
• 50 Groups CTSS/105Groups DCS
• Multi Step Frequency:(5K/6.25K/10K/25K/50K/100K)
• Multi Scan
• VOX Transmission
• Transmit Overtime Voice Prompt
• Begin/End Transmitting BEEP Prompt
• Auto/Manual Keypad Lock
• Wire Clone, Programmable By Computer
• Stopwatch Function
• Lowe Voltage VOICE prompt
• Busy Channel Lockout

 Technical Specification:
KG-UVD1P Technical Specification

Frequency Range

Frequency Range Can Be Suitable For Different Countries or Areas
136-174&350-470 MHz (RX/TX)
136-174&400-480 MHz (RX/TX)
136-174&420-520 MHz (RX/TX)
136-174&400-470 MHz (RX/TX)
136-174&245-250 MHz (RX/TX)
136-174&216-280 MHz (RX/TX)
136-174&225-226 MHz (RX/TX)
144-146&430-440 MHz (RX/TX)
FM: 76-108 MHz(RX)

Memory Channels

128 channels

Frequency Stability

2.5ppm

Operating Voltage

7.4V

Operating Temperature

 -30℃~+60

Waterproof
IP 55

Antenna Impedance

50Ω

Dimension

5810538(mm)

Weight

250g

Transmitter

Frequency Stability

2.5PPM

RF Carrier Power

UHF: 4W VHF: 5W

Effective Radiation Power (ERP)

within pre-determined value 7.5dB

Max. Frequency Deviation

Channel Space: 25KHz  5KHz

Channel Space: 12.5KHz 2.5KHz

Audio Modulation

+3dB (pre-emphasis by 6dB between 0.3-3KHz)

Adjacent Channel Power

Channel Space: 25KHz  ≥70 dB

Channel Space: 12.5KHz  ≥60 dB

Spurious Radiation

≤-30dBm

Inter modulation Attenuation

≥40dB

Modulation Distortion

≤10%

Residual FM

≤-35dB

Residual AM

≤3%

Receiver

Sensitivity (12dB SINAD

0.16V

Squelch Rejection Sensitivity

≤0.8V

Squelch Sensitivity

≤0.2V

Audio Output power

500mW

Audio Distortion

≤5%

Audio Response

300-3000Hz)  +1 to -3dB

Co-channel Rejection

≥-8.0dB

Performance of Amplitude Limiter

≤3

Adjacent Channel Selection

Channel Space: 25KHz  ≥70 dB

Channel Space: 12.5KHz  ≥60 dB

Inter-modulation

≥65 dB

Resistance

≥84 dB

Spurious Radiation

9KHz-1GHz≤-57dBm

1GHz-4GHz≤-47dBm
