TECHNICAL SPECIFICATION
| Ranges |
400 - 480MHz , 430-520MHz
136-174MHz , PMR446MHz |
| Channel Numbers |
16 |
| Openating Mode |
Co-channel or Dis-channel Simplex |
| Output Power |
UHF H:8W , M:4W , L:1W
VHF H:8W , M:5W , L:1W
PMR 0.5W
|
| Voltage(DC) |
7.4V |
| Working Temperature |
-30℃ ~ +60℃ |
| Modulation Type |
FM(F3E) |
| Max. Frequency Deviation |
≤±5KHz |
| Frequency Stability |
±5PPM |
| Sensitivity (12dB SINAD) |
≤0.2µV |
| Audio Output power |
≥500mW |
| Spurious Radiation |
< -60dB |
| Weight |
320 G |
| Size |
128 x 53 x 31 MM |
|
