kg-uvr5

Dual Frequency , Car Mobile Radio KG-UVR5

MAIN  FUNCTION
  • 999memory channels
  • Unidirectional or Two Way Cross Band Repeater
  • Dual Frequency Display
  • Dual Independant Operation System
  • Remote Control Function
  • Voice scrambler, DTMF Encode&Decode
  • Front panel and radio body flexible for separation
  • CTCSS/DCS encoding and decoding
  • Non-standard CTCSS/DCS setting freely
  • Same -band repeat on two combined radios
  • Dual track and multi-way loudspeakers
  • Hand microphone DTMF with loudspeakers
  • Caller ID display
  • Multiple back light color select able
  • Scan channel adding /deleting
  • Grouping channel scanning
  • Group calls, all calls and selective calls
  • Priority channel scanning
  • APO power management
  • Wide / narrow bandwidth select able
  • Voice guide
  • Automatic temperature detection
  • Stun/kill function
  • Single audio pulse frequency
  • Multiple scanning ways
  • Remote control setting
  • Multiple setting for cooling fan
  • Superheterodyne Receiver Type


TECHNICAL SPECIFICATION

Intergration
Frequency Range    RX and TX
   136-174MHz & 200-320MHz
   FM , 65MHz-108MHz
Step 5KHz/6.25KHz/10KHz/12.5KHz 25KHz/50KHz/100KHz
Channel Number 999
Work Mode F2D / F3E
Operating Temperature -20℃~+60℃
Voltage 13.8VDC±15%
Antenna Impedance 50Ω
Weight 1438 g
Size 140 x 44 x 207 MM



Receiver
  Wide Narrow
Adjacent Channel Selectivity ≤70dB ≤60dB
Inter Modulation ≤65dB ≤60dB
Spurious Response ≤70dB ≤70dB
Audio Response 1~-3dB(0.3~3KHz) 1~-3dB(0.3~3KHz)
Signal to Noise Ratio ≥45dB ≥40dB
Audio Distortion ≤5%
Audio Power transceiver≤3w ,
hand microphone≤1w
Sensitivity UHF/VHF:0.25µV(12dB SINAD)



Transmitter
Adjacent Channel Power ≥70dB ≥60dB
Type of Modulation 16K F3E 11K F3E
Spurious ≥60dB ≥60dB
Signal to Noise Ratio ≥40dB ≥36dB
Audio Response 1~-3dB(0.3~3KHz) 1~-3dB(0.3~3KHz)




Please Click The Icon to Select The Items You Want
And Send The Inquiry to WOUXUN For Offers

STANDARD  ACCESSORY

MMO-001   SAO-001
microphone ...

switchboard ...
Hand Microphone   Inclined Switchboard

SAO-002   MBO-001
switchboard ...

mounting bracket ...
Flat Switchboard   Mounting Bracket

RBO-001   PWO-002
panel bracket ...

power cord ...
Front Panel Bracket   Mobile Power Cord

SCO-002   SSO-001
extension cable ...

screw sets ...
Extension Cable   Screw Sets

FUO-001
fuse ...

Fuse , 15A 32V


OPTIONAL  ACCESSORY

SPO-002   PCO-003
switching power ...

usb cable ...
Switching Power , 30A   USB Cable

ANO-015   ANO-016
antenna ...

magnetic mount ...
Mobile Antenna   Magnetic Mount
