| General |
| Audio Power |
≤500 mW |
| Operating Temperature |
-20 ℃～+40 ℃ |
| Voltage |
13.8 VDC |
| Setp |
100Hz / 1KHz / 10KHz / 100KHz / 1MKhz |
| Frequency Range |
26-27 MHz |
| Memory Channels |
999 |
| Mode |
F2D / F3E |
| Antenna Impedance |
50Ω |
| Analogue Transmitter |
| |
Wide |
Narrow |
| Adjacent Channel Selectivity |
≤ 70dB |
≤ 60dB |
| Inter-Modulation |
≤ 65dB |
≤ 65dB |
| Spurious Response |
≤ 70dB |
≤ 70dB |
| Audio Response |
+1~-3dB(0.3~3KHz) |
+1~-3dB(0.3~3KHz) |
| Squelch Sensitivity |
≥45dB |
≥40dB |
| Audio Distortion |
≤5% |
| Output Power |
25W |
|
| Analogue Receiver |
| |
Wide |
Narrow |
| Modulation |
16K F3E |
11K F3E |
| Effective Radiation Power |
≥70dB |
≥60dB |
| Spurious Response |
≥60dB |
≥60dB |
| Audio Response |
+1~-3dB(0.3~3KHz) |
+1~-3dB(0.3~3KHz) |
| Max Offset |
±5KHZ |
±2.5KHZ |
| Frequency Stability |
±2.5PPM |
| Audio Distortion |
≤5% |
|
